DH24HV/ DH28HV/ DH34HV
Continuously variable speed drilling machines
Powerful brushless drive with particularly smooth action and high
performance with almost constant torque over the entire speed range
● Smooth action thanks to polished multi-tooth carrier
● Guaranteed concentricity guaranteed to be less than 0.015 mm measured in the drilling spindle sleeve
● Separate emergency stop button
● Digital speed display integrated in housing
● Generously dimensioned, height adjustable protective screen with safety switch for greatest possible user cover
● Single-piece, pressure cast aluminium spindle sleeve lever (B 24HV with Softgrip handles)
● Drilling depth stop
● V-belt cover with safety switch
● V-belt tensioning device
● Right-handed/left-handed rotation
● Machine lamp integrated in drilling head
● Precision workmanship; rugged drilling table with diagonal T-slots, 360° rotation and all-around cooling water channel
● Thick walled cast column for high force absorption and stability
● Solid baseplate, large dimensions and pronounced ribbing on rear
